Portable Lighting is a segment
where, in addition to convenience and ease of use, the need for professional performance is
becoming more and more important. SOUNDASTION 4LEDKIT-COB is the answer to all
these requirements and offers a set of 4 LED Pars, each with the possibility to
change the emission beam angle between 90° (with basic clear lens) and 30° by
easily installing a Fresnel lens (supplied). This allows to choose whether or
not to concentrate their light beam according to the user’s requirements. It is
even possible to create mixed combinations of different emission beams, in case
of multiple lighting needs.
Each PAR has a powerful and reliable 30W RGB 3in1 LED.
COB technology – literally: Chip On Board - allows better mixing of basic
colors generated by LEDs yet maintaining brightness, reliability and heat
dissipation of normal chips.
The 4LEDKIT-COB bar is about 1-meter-long with four
horizontally/vertically adjustable Pars. On it you can find, in addition to
control panel, mains and DMX connectors, two VDE sockets to power any other DMX-controllable
fixtures which, among other things, can be mounted on the upper part of the bar
by using the two provided holes (one on each edge). The bar, moreover, may also
be placed on the floor, by mounting the two supplied brackets as feet, and used
as washer bar.
The kit also includes a 2.5m tripod stand, a 3-footswitch
pedalboard for remote control of main functions and a practical soft case with
side pocket for easily transport the kit (stand excluded).
- Bar with 4 ultralight PARs with 30W RGB 3in1 COB LEDs
- Up to 1775 lux @ 1m (RGB emission of single PAR with Fresnel lens)
- Clear lens with 90° beam angle
- Fresnel lens - easily removable - with 30° beam angle
- 4 operation mode: Sound test, Auto run, Strobe, DMX control and Master/Slave
- LED display and control panel easy to control
- DMX512 modes: 1CH, 3CH,7CH,12CH and 16CH
- Pedalboard with 3 switches. 4m cable with 5 poles connector
- Soft-case for the bar, pedalboard and cables
- 2.5m height lighting support (included)
The DMX512 control has 5 different modes: 1, 3,
7, 12 and 16 channels, allowing to simplify or make more detailed the control,
depending on the needs. There are, finally, Auto-Run, Strobe, Sound and DMX
Master/Slave functions to obtain excellent lighting effects even in the absence
of an external DMX controller.
4LEDKIT-COB - Features
