WF-V21HHB Dual VHF Plug and Play Wireless Microphone with 2 Handheld Mics (205.75 MHz - 209.8 MHz)

Download product sheet
WF-V21 is the answer to all those who need a reliable, high-quality sound, and easy to use set of wireless microphones. Ideal in educational, Portable Sound, Public Address, and DJ contexts, the WF-V21 impresses with its brilliant and warm sound, thanks to the quality of components and the capsule designed for all application.
WF-V21 is the answer to all those who need a reliable, high-quality sound, and easy to use set of wireless microphones. Ideal in educational, Portable Sound, Public Address, and DJ contexts, the WF-V21 impresses with its brilliant and warm sound, thanks to the quality of components and the capsule designed for all application.

Product downloads

Product details

Key features

  • VHF Transmission with SMD Technology
  • 2 available Pairs of Frequencies in VHF Band
  • Simple user Interface for plug and play setup
  • 30m ideal distance (without obstacles)
  • 2 Handheld microphones with high-quality dynamic cardioid capsules

Specifications

  • Carrier Frequency
    VHF 200 - 215.3 MHz
  • Operating Frequencies
    205.75 MHz - 209.8 MHz
  • Frequency Stabilization
    Automatic calibration
  • Dynamic Range
    > 90dB
  • Total Harmonic Distortion
    < 0.5%
  • Frequency Response
    40Hz - 16kHz / ±3dB
  • Packing Dimensions (WxHxD)
    436 x 104 x 324 mm
  • Packing Gross Weight
    2.0 kg
  • Receiver Power Supply
    DC12V, 500mA
  • Receiver Consumption
    < 4W
  • Signal/Noise Ratio
    > 95dB
  • Receiving Sensitivity
    10dBuV
  • De-Emphasis
    75uS
  • Audio Output Level
    Balanced 400mV; Unbalanced 400mV
  • Receiver Size (WxHxD)
    211 x 43 x 115 mm (antennas not incl.)
  • Antenna Length
    110 mm (min.) 430 mm (max.)
  • Net Weight
    0.295 kg
  • Transmitter Power
    10mW
  • Modulation Type
    FM
  • Deviation
    37KHz
  • Battery Voltage
    3V (2x1.5V AA-Type Batteries)
  • Continuous Using
    7 hours
  • Hand-held Mic. Size (W/DxH)
    Ø33 (min) - Ø48 (max) x 240 mm
  • Hand-held Mic. Net Weight
    0.218 kg (batteries included)
